Sensor |
384x288 pix. @ 17 micrometres |
Objective Lens |
F50/1.2 |
Magnification |
3.5-14x |
Field Of View (Hxv), Degrees / M@100M |
7.5x5.6 |
Detection Range |
1800m |
|
Sensor Type |
uncooled |
Sensor Resolution |
384x288 pixels |
Sensor Pixel Pitch |
17 micrometres |
Sensor Frame Rate |
50Hz |
|
Optics Objective Lens |
F50/1.2 |
Optics Magnification |
3.5-14x |
Optics Field Of View(Hxv), Degrees / M @ 100 M |
7.5x5.6 |
Optics Eye Relief |
50mm |
|
Display Type |
AMOLED |
Display Resolution |
1024x768 pixels |
|
Range Detection Range |
1800mm |
|
Reticle Click Value |
13H/V / 13mm at 100m |
Reticle Click Range |
2600H/V / 2600mm at 100 m |
Reticle Number Of Preloaded Reticles |
10 |
|
Video/Photo Resolution |
1024x768 pixels |
Video / Photo Format |
.mp4 / .jpg |
Built-In Memory |
16GB |
|
Wireless Standard |
802,11 b/g |
Frequency |
2.4GHz |
Line-Of-Sight Reception Range |
15m |
|
Degree Of Protection |
IPX7 (IEC60529) |
Operating Temperature Range |
-25 Degree Celcius - +50 Degree Celcius |
|
Power Supply Output Voltage |
3.0V - 4.2V |
Battery Type |
Dual Li-Ion B-Pack Mini Power System 2 Ah Changeable Battery (external) / 3.2 Ah Battery (internal) |
Capacity |
2000mAh (external) + 3200mAh (internal) |
Operating Time On Battery Pack (At T=22°C) |
7 Hours |
External Power Supply |
5V |
|
Max. Recoil Power On Rifled Weapon (Eo) |
6000 Joules |
Shock Resistance On The Smooth-Bore Rifles |
12 caliber |
Mounting Brackets On Weapon |
Standard 30mm rings |
|
Dimensions |
407mmX78mmX80mm |
Weight |
0.9kg |
